At Muvro Conveyor Systems, we offer a wide range of conveyor solutions, including Inclined PVC Belt Conveyors, designed to facilitate smooth and efficient material transport across different elevation levels. These conveyors are an excellent choice for industries such as food processing, packaging, warehouse automation, e-commerce, assembly, and logistics, where products need to be moved seamlessly between different heights. One of the key advan...
Our Inclined PVC Belt Conveyors come in a variety of customizable designs to meet specific material handling needs. They can be manufactured with different incline angles up to 30degree, depending on the requirements of the operation. Additional features such as side guards, chutes, and hoppers can be integrated to optimize efficiency and product flow.
Energy efficiency and low maintenance are two additional benefits of using an inclined PVC belt conveyor. These conveyors require minimal power consumption while delivering high performance, making them a cost-effective solution for businesses. Their simple yet robust construction ensures reliability and reduces the need for frequent repairs or maintenance interventions
Used to transport goods between different floors or storage levels efficiently
Benefit from their hygienic and easy-to-clean properties, making them ideal for handling raw or packaged food products
Moving parts or products seamlessly through various stages of production.
Comes with free-flow universal rollers, adjustable speed control, modular construction, and AC geared motor drive, designed for efficient, customizable material handling across industrial applications.
25 to 150 kg/mtr.
Load Capacity
10-75m/min
Conveying Speed
Up to 30 degree
Incline/Decline
230~415V
Rated Voltage
0.5kw~5.0kw (Customize)
Electrical Power
AC Gear Motor
Motor Type
Free Flow universal roller
Roller Type
Ø50 mm, Ø60mm
Roller Diameter
Steel | 1.5mm/3mm, zinc-plated
Roller Material
1200mm
Mounting Pitch (for return roller)
450mm to 800mm
Mounting Pitch (for top roller)
Smooth, 2-layer, PVC, longitudinally grooved for incline
Conveyor Belt
Steel Sheet 1.5mm to 3mm
Slider Bed
600mm, 800mm, 1000mm, 1200mm, 1500mm
Between Frame
BF+100mm (Customize)
Total Width
UPTO 30mtr Max
Module Length
50mm to 600mm (Customize)
Side Guide
700± 50mm Adjustable *(400 to 5000 height available as per requirement)
Height
